"2014 Dynapac CP275 Pneumatic Roller RPN### - 14,000 kg"

Dynapac CP275 Pneumatic Roller RPN### (2014) – 14,000 kg

ReflowX SKU: REF-1487

Product Details

  • Quantity
    1
  • Availability (Lead Time)
    N/A
  • Product Location
    United Arab Emirates
  • Condition
    Surplus
  • OEM
    Dynapac
  • Equipment code
  • Total Price
  • Per Unit Price
    $49,500
Chat With Seller

Description

Dynapac CP275 Pneumatic Roller (2014 Model) - Description & Specifications

General Overview:

The Dynapac CP275 is a high-performance pneumatic roller designed for the compaction of various materials, especially in road construction and asphalt paving. It is equipped with multiple tires to provide uniform pressure distribution, making it ideal for use on both asphalt and granular materials. The machine is engineered to deliver superior compaction efficiency and high productivity on large-scale projects.

Key Specifications:

  • Model: Dynapac CP275
  • Year: 2014
  • Operating Weight: 14,000 kg (approximately 30,865 lbs)
  • Tire Configuration: Typically features 9 or 11 pneumatic tires, depending on the specific version (3 axles).
  • Tire Pressure: Adjustable, typically between 4.5 to 7 bar (65 to 100 psi), allowing for optimal compaction.
  • Engine Power: 93 kW (125 hp) – this engine power ensures excellent compaction performance.

Dimensions:

  • Overall Length: 5,450 mm (214.6 inches)
  • Overall Width: 2,250 mm (88.6 inches)
  • Overall Height: 3,150 mm (124.0 inches)
  • Wheelbase: 2,940 mm (115.8 inches)
  • Ground Clearance: 370 mm (14.6 inches)

Engine & Performance:

  • Engine Type: Diesel
  • Engine Model: Commonly equipped with a Cummins QSB4.5 engine or a similar engine for reliable performance.
  • Max Speed: Approximately 19 km/h (11.8 mph), allowing for efficient movement between sites.
  • Fuel Tank Capacity: 150-200 liters (39.6 - 52.8 gallons), offering extended work periods without refueling.
  • Hydraulic System: Operates the tire pressure and steering system effectively for stability and ease of operation.

Compaction Features:

  • Pneumatic Tires: The 9-11 tires are mounted on three axles, providing a high-quality surface compaction. The flexibility of the tires allows for an even distribution of the compaction force across the surface, preventing any damage to the material.
  • Tire Pressure Control System: Pneumatic tire pressure is adjustable, providing flexibility to adapt to different surface conditions and compaction requirements. The pressure can be monitored and adjusted to ensure maximum compaction efficiency.

Hydraulic & Drive System:

  • Drive System: Hydrostatic drive system for both forward and reverse travel. This allows for smooth and precise control during operation.
  • Steering: The pneumatic roller is equipped with a smooth and responsive steering system, making it ideal for tight spaces and maneuverability on varied construction sites.

Operator Comfort & Controls:

  • Operator's Cabin: The cabin offers a comfortable, ergonomic environment for the operator, with vibration reduction and easy-to-use controls.
  • Visibility: The cabin provides excellent visibility, allowing the operator to monitor the work area closely and maintain safety during operations.
  • Control System: Simple and intuitive controls for tire pressure settings, steering, and other hydraulic functions. The control layout ensures the operator can easily manage the machine’s functions without distraction.

Safety Features:

  • Rollover Protection (ROPS/FOPS): Designed with rollover protection, ensuring the safety of the operator.
  • Warning Systems: Equipped with audible and visual warnings for tire pressure issues, low fuel, and operational safety alerts.

    For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com



General Terms

  • ReflowX and the seller retain the right to evaluate and approve offers.
  • Buyers should verify quantities and conditions upon delivery.
  • After successful engagement, both buyer and seller manage communication for payment terms and delivery schedule.
  • All parties agree to adhere to ReflowX Terms and Conditions in transactions.
  • Buyers can request value-added services such as pre-purchase inspections, Expediting & Delivery Services through ReflowX. Contact us!
