Cummins QSK 60-G5 Generator Set (2015/2016) Specifications | High-Efficiency Diesel Power

CUMMINS QSK 60 -G5 Generator Set (2015/2016)

ReflowX SKU: REF-7071

Product Details

  • Quantity
    7
  • Availability (Lead Time)
    N/A
  • Product Location
    China
  • Condition
  • OEM
    ReflowX
  • Equipment code
    gen-d
  • Total Price
  • Per Unit Price
    $335,500
Chat With Seller

Description

Cummins QSK 60-G5 Generator Set (2015/2016) Specifications:

Engine Specifications:

  • Engine Model: Cummins QSK 60-G5
  • Engine Type: 4-stroke, Turbocharged, Intercooled
  • Cylinders: 16 cylinders, V-type configuration
  • Displacement: 60 L (3,660 cubic inches)
  • Bore x Stroke: 170 mm x 170 mm (6.7 in x 6.7 in)
  • Compression Ratio: 14.0:1
  • Aspiration: Turbocharged and Intercooled
  • Fuel Type: Diesel (with optional dual fuel capabilities)
  • Governor: Electronic
  • Cooling System: Water-cooled, closed-loop cooling system
  • Lubrication: Full-flow filtration system

Performance Data:

  • Prime Power Output: 2,000 kWe (2,500 kVA)
  • Standby Power Output: 2,200 kWe (2,750 kVA)
  • Rated Speed: 1,800 RPM (60 Hz), 1,500 RPM (50 Hz)
  • Fuel Consumption: Approx. 0.35–0.45 L/kWh at full load (depending on fuel quality)
  • Heat Rate: Approx. 9,500–10,500 Btu/kWh depending on load and application
  • Efficiency:
    • Electrical Efficiency: Approx. 40-42% at full load
    • Total Efficiency: Can achieve up to 85-90% with Combined Heat and Power (CHP) applications
  • Exhaust Temperature: Approx. 480°C (896°F) at full load
  • Exhaust Back Pressure: Low exhaust back pressure for optimized performance

Emissions and Environmental Compliance:

  • Emissions Standards: Meets EPA Tier 2 and EU Stage IIIA emissions regulations
  • NOx: Approx. 0.5–0.8 g/kWh (depends on load and fuel)
  • CO: Approx. 1.5–2.0 g/kWh at full load
  • UHC (Unburned Hydrocarbons): Meets low emissions requirements for better environmental compliance

Alternator and Electrical System:

  • Alternator Type: Brushless, synchronous alternator with integrated excitation system
  • Voltage: Configurable options: 380V, 400V, 480V, 600V, or custom voltage configurations
  • Frequency: 50 Hz (Europe) or 60 Hz (North America)
  • Power Factor: 0.8 lagging (typical for industrial applications)
  • Voltage Regulation: ±1% of rated voltage under all operating conditions
  • Protections: Comprehensive protection system for overload, short circuit, and under/over-voltage

Dimensions and Weight:

  • Length: Approx. 6,500 mm (256 inches)
  • Width: Approx. 2,400 mm (94 inches)
  • Height: Approx. 2,500 mm (98 inches)
  • Weight: Approx. 24,000 kg (52,910 lbs) depending on the configuration

Fuel System:

  • Fuel Type: Diesel (Dual-fuel option available for some configurations)
  • Fuel Tank Capacity: Typically external, varies based on the configuration, providing several hours of runtime
  • Fuel Consumption: Approx. 0.35–0.45 L/kWh at full load (diesel)
  • Fuel Pressure: Typical fuel pressure of 0.4–0.8 bar (5.8–11.6 psi) depending on configuration
  • Dual Fuel Capability: Available for natural gas and diesel applications in certain configurations

Cooling and Exhaust:

  • Cooling System: Closed-loop water cooling with radiator and heat exchangers
  • Exhaust Temperature: Approx. 480°C (896°F) at full load
  • Exhaust Back Pressure: Optimized for low exhaust back pressure to maximize fuel efficiency
  • Exhaust System: Includes standard muffler, optional exhaust after-treatment for enhanced emissions control

Control and Monitoring:

  • Control Panel: Cummins PowerCommand 3.3 (or equivalent) for control, diagnostics, and monitoring of engine and generator systems
  • Monitoring Parameters: Engine speed, voltage, current, power factor, fuel consumption, exhaust temperature, and other critical operational data
  • Remote Monitoring: Available with Cummins telematics and remote monitoring options for real-time performance data and alerts
  • Protection System: Comprehensive protection including low oil pressure, high coolant temperature, overvoltage, overcurrent, and other critical alarms

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com



General Terms

  • ReflowX and the seller retain the right to evaluate and approve offers.
  • Buyers should verify quantities and conditions upon delivery.
  • After successful engagement, both buyer and seller manage communication for payment terms and delivery schedule.
  • All parties agree to adhere to ReflowX Terms and Conditions in transactions.
  • Buyers can request value-added services such as pre-purchase inspections, Expediting & Delivery Services through ReflowX. Contact us!
