Siemens SGT-400 DLE Gas Turbine (2013) | High Efficiency & Low Emissions for Power Generation

SIEMENS SGT 400 DLE Gas Turbine (2013)

ReflowX SKU: REF-3989

Product Details

  • Quantity
    1
  • Availability (Lead Time)
    N/A
  • Product Location
    China
  • Condition

    USED SURPLUS

  • OEM
    ReflowX
  • Equipment code
    CFIHOS-30000534
  • Total Price
  • Per Unit Price
    $3,580,500
Chat With Seller

Description

Siemens SGT 400 DLE Gas Turbine - Full Specifications (2013 Model)

General Information

  • Model: Siemens SGT 400 DLE (Dry Low Emission)
  • Manufacturer: Siemens Energy
  • Year of Manufacture: 2013
  • Operating Hours: 11,000 hours (total runtime)

Electrical Specifications

  • Power Output: 13 MW (Nominal Power Output)
  • Voltage: 10.5 kV
  • Frequency: 50 Hz (standard for regions with 50 Hz electrical grids)

Mechanical Specifications

  • Gearbox: Allen Gear (Note: Used for mechanical power transmission to generators, ensuring proper speed adjustment)
  • Speed: Approximately 3,600 rpm (typical turbine speed for industrial applications)
  • Compressor: Axial-flow compressor with 14 stages
  • Turbine: 2-stage axial-flow gas turbine

Fuel and Emissions

  • Fuel Type:
    • Primary: Natural Gas
    • Secondary: Light distillate fuel (in case of natural gas unavailability)
  • Combustion Type: Dry Low Emission (DLE) technology, designed to reduce NOx and CO emissions to meet environmental standards.

Efficiency and Performance

  • Thermal Efficiency: Around 38-40% (depending on operational conditions and configuration)
  • Exhaust Temperature: Approximately 570–600°C (varies depending on operational conditions)

Dimensions and Weight

  • Dimensions (approx.):
    • Length: 9.7 m
    • Width: 3.4 m
    • Height: 3.8 m
  • Weight: Approximately 32 tons (depending on configuration)

Additional Features

  • Fuel Flexibility: Can switch between natural gas and liquid fuels (light distillate), offering greater operational flexibility.
  • DLE Combustion: The Dry Low Emission technology ensures that the turbine runs with reduced nitrogen oxides (NOx) and carbon monoxide (CO) emissions, which is particularly beneficial for compliance with environmental regulations.
  • Operational Flexibility: The turbine is designed to operate in varying load conditions, making it suitable for both base-load and load-following operations.



For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
