Siemens SGT-400 DLE Gas Turbine (2013) | High Efficiency & Low Emissions for Power Generation

SIEMENS SGT 400 DLE Gas Turbine (2013)(001)

ReflowX SKU: REF-8800

Product Details

  • Quantity
    1
  • Availability (Lead Time)
    N/A
  • Product Location
    China
  • Condition
  • OEM
    ReflowX
  • Equipment code
    CFIHOS-30000534
  • Total Price
  • Per Unit Price
    $4,510,000
Chat With Seller

Description

Siemens SGT-400 DLE (Dry Low Emission) Gas Turbine Specifications

General Overview

  • Manufacturer: Siemens Energy
  • Model: SGT-400 DLE (Dry Low Emission)
  • Type: Industrial Gas Turbine
  • Year of Manufacture: 2013

Key Performance Specifications

  • Power Output: 13 MW (Nominal power)
  • Voltage: 11 kV
  • Frequency: 50 Hz (Common for regions with 50 Hz electrical grids)
  • Operational Hours: 5,000 hours (Total runtime, may vary depending on the operational conditions)
  • Efficiency: Approx. 38-40% (depending on operational conditions and configuration)

Operational and Design Parameters

  • Speed: Approximately 3,600 rpm
  • Compressor: Axial-flow compressor with 14 stages
  • Turbine: 2-stage axial-flow gas turbine
  • Fuel:
    • Natural Gas (Primary)
    • Light distillate fuel (Secondary)
  • Cooling: Air-cooled (for the rotor and stator)
  • Combustion Type: Dry Low Emission (DLE) combustion system, designed to reduce NOx and CO emissions
  • Exhaust Temperature: Approx. 570-600°C (depending on load and operating conditions)

Design Features

  • Dry Low Emission (DLE): The DLE system minimizes nitrogen oxide (NOx) emissions by using advanced combustion technology.
  • Fuel Flexibility: Capable of operating with natural gas or liquid fuels (light distillates), offering flexibility in fuel sources.
  • Compact Design: Optimized for compact footprint and easier integration into industrial applications.
  • Reliability: Known for high reliability and availability in both base-load and load-following operation.

Dimensions and Weight

  • Length: Approx. 9.7 m
  • Width: Approx. 3.4 m
  • Height: Approx. 3.8 m
  • Weight: Approx. 32 tons (depends on configuration)

Emissions

  • NOx (Nitrogen Oxides): Reduced emissions due to the DLE combustion system
  • CO (Carbon Monoxide): Low levels due to the optimized combustion process

Advantages

  • High fuel efficiency and low emissions
  • Flexible fuel options
  • Compact and robust design
  • Low maintenance costs and long intervals between major overhauls
  • High reliability and operational flexibility, suitable for varying load conditions


For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com



General Terms

  • ReflowX and the seller retain the right to evaluate and approve offers.
  • Buyers should verify quantities and conditions upon delivery.
  • After successful engagement, both buyer and seller manage communication for payment terms and delivery schedule.
  • All parties agree to adhere to ReflowX Terms and Conditions in transactions.
  • Buyers can request value-added services such as pre-purchase inspections, Expediting & Delivery Services through ReflowX. Contact us!
