Siemens SGT-400 DLE Gas Turbine (2016) | High Efficiency & Low Emissions for Power Generation

SIEMENS SGT 400 DLE Gas Turbine (2016)

ReflowX SKU: REF-7292

Product Details

  • Quantity
    1
  • Availability (Lead Time)
    N/A
  • Product Location
    China
  • Condition

    USED SURPLUS

  • OEM
    ReflowX
  • Equipment code
    CFIHOS-30000534
  • Total Price
  • Per Unit Price
    $5,775,000
Chat With Seller

Description

Siemens SGT 400 DLE Gas Turbine - Full Specifications (2016 Model)

General Information

  • Model: Siemens SGT 400 DLE (Dry Low Emission)
  • Manufacturer: Siemens Energy
  • Year of Manufacture: 2016
  • Operating Hours: 2,955 hours (total runtime)

Electrical Specifications

  • Power Output: 14.4 MW (Nominal Power Output)
  • Voltage: 10.5 kV
  • Frequency: 50 Hz (common for regions with 50 Hz electrical grids)

Mechanical Specifications

  • Starter Operations: 80 start cycles (this indicates the number of times the turbine has been started from cold or idle condition, a common maintenance reference to gauge wear and tear on components such as the starter motor)
  • Compressor: Axial-flow compressor (typically with 14 stages)
  • Turbine: 2-stage axial-flow gas turbine
  • Gearbox: Usually equipped with a gearbox (Allen Gear or similar) for transmission to the generator, ensuring optimal speed matching.

Fuel and Emissions

  • Fuel Type:
    • Primary Fuel: Natural Gas
  • Combustion Type: Dry Low Emission (DLE) technology, designed to reduce NOx and CO emissions and maintain high efficiency.

Performance & Efficiency

  • Thermal Efficiency: Around 38-40% (depending on operational conditions)
  • Exhaust Temperature: Typically between 570–600°C (varies with load and operational parameters)
  • Power Output: 14.4 MW, which is slightly higher than the previous 13 MW specification you mentioned (indicating the configuration is optimized for more output).

Dimensions and Weight

  • Dimensions (approx.):
    • Length: 9.7 m
    • Width: 3.4 m
    • Height: 3.8 m
  • Weight: Around 32 tons (weight varies slightly depending on the configuration and additional accessories)

Additional Features

  • DLE Technology: The Dry Low Emission combustion system reduces the environmental impact, lowering nitrogen oxides (NOx) and carbon monoxide (CO) emissions.
  • Fuel Flexibility: Although primarily designed for natural gas, the turbine can be switched to liquid fuels (light distillate) if needed.
  • High Reliability: Known for low downtime, it’s a preferred choice for plants requiring continuous power generation and operational flexibility.

Advantages

  • High Efficiency: With a power output of 14.4 MW, it delivers higher performance than some older models.
  • Reduced Emissions: The DLE combustion system ensures low emissions, making it environmentally friendly.
  • Low Maintenance Costs: Thanks to the long intervals between overhauls and relatively low wear from 2,955 operating hours.
  • Starter Performance: With 80 start cycles, the starter and associated components still have considerable lifespan left.



For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com



General Terms

  • ReflowX and the seller retain the right to evaluate and approve offers.
  • Buyers should verify quantities and conditions upon delivery.
  • After successful engagement, both buyer and seller manage communication for payment terms and delivery schedule.
  • All parties agree to adhere to ReflowX Terms and Conditions in transactions.
  • Buyers can request value-added services such as pre-purchase inspections, Expediting & Delivery Services through ReflowX. Contact us!
