Solar Mars 100 Gas Turbine (2015) Specifications | High-Efficiency Power Generation

Solar Mars100 Gas Turbine (2015)

ReflowX SKU: REF-6591

Product Details

  • Quantity
    1
  • Availability (Lead Time)
    N/A
  • Product Location
    Germany
  • Condition
  • OEM
    ReflowX
  • Equipment code
    CFIHOS-30000534
  • Total Price
  • Per Unit Price
    $1,925,000
Chat With Seller

Description

Solar Mars 100 Gas Turbine (2015) Specifications:

General Engine Specifications:

  • Model: Solar Mars 100
  • Year: 2015
  • Turbine Type: Industrial gas turbine, axial flow, turbocharged
  • Configuration: Single-shaft
  • Compressor: Axial-flow, 14-stage
  • Turbine: Single-stage power turbine
  • Combustion System: Dry Low Emissions (DLE) for low NOx, CO, and UHC emissions
  • Cooling System: Air-cooled
  • Fuel Type: Natural Gas or Liquid Fuels (depending on configuration)
  • Control System: Digital electronic controls for integration with plant control systems

Performance Data:

  • Power Output:
    • Nominal Power: 13.8 MW (18,500 HP) at ISO conditions
    • Maximum Power: Up to 15 MW (depending on operating conditions and fuel type)
  • Operating Speed: 3,600 RPM (standard for 50 Hz operation)
  • Fuel Consumption (Natural Gas):
    • Specific Fuel Consumption: Approx. 0.33-0.35 lb/kWh (0.5-0.53 kg/kWh) at full load
  • Exhaust Temperature: 440°C (824°F) at full load
  • Thermal Efficiency: Typically around 34-36% at full load
  • Heat Rate: Approx. 10,200-10,500 Btu/kWh

Dimensions and Weight:

  • Length: Approx. 5,590 mm (220 inches)
  • Width: Approx. 2,400 mm (94.5 inches)
  • Height: Approx. 2,440 mm (96 inches)
  • Weight: Around 17,500 kg (38,500 lbs) depending on configuration

Emissions and Environmental Compliance:

  • Emissions:
    • NOx Emissions: As low as 25 ppm (parts per million) at 15% O2 for natural gas
    • CO Emissions: As low as 25 ppm at full load
    • UHC Emissions: Ultra-low emissions when configured with Dry Low Emissions (DLE) combustor
  • Environmental Standards: Meets global emissions regulations, including EPA Tier 2 and European Union Stage IIIA emissions standards.

Fuel System:

  • Fuel Type: Natural gas (primary), but can also operate on liquid fuels (diesel or kerosene).
  • Fuel System:
    • Natural Gas: Single fuel or dual fuel (natural gas and liquid fuel) operation
    • Fuel Gas Pressure: 4-6 bar (58-87 psi) for natural gas
    • Fuel Consumption at Full Load: Approx. 3,500-3,800 Nm³/h (Natural Gas)

Starting System:

  • Starting Method:
    • Electric Starter: Using a high-torque electric motor
    • Start Time: Typically 5-10 minutes for start-up
  • Auxiliary Power: Typically requires external power for startup (can be supplemented by on-site generators or grid power)

Control & Monitoring:

  • Control System:
    • Solar turbine controller with digital controls
    • Advanced diagnostics with integrated remote monitoring options
    • HMI (Human-Machine Interface) for real-time monitoring and operation
    • Optional SCADA Integration for seamless plant management
  • Instrumentation: Includes temperature, pressure, and vibration sensors, and monitors engine health and performance.

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com



General Terms

  • ReflowX and the seller retain the right to evaluate and approve offers.
  • Buyers should verify quantities and conditions upon delivery.
  • After successful engagement, both buyer and seller manage communication for payment terms and delivery schedule.
  • All parties agree to adhere to ReflowX Terms and Conditions in transactions.
  • Buyers can request value-added services such as pre-purchase inspections, Expediting & Delivery Services through ReflowX. Contact us!
