Product Details

Quantity

Availability (Lead Time)

0-2 Weeks

Product Location

Indonesia

Condition

Used Surplus

Supplier

ReflowX

Equipment code

CFIHOS-30000685

Description

The Ansaldo Energia AE94.2 turbines form part of a complete power plant setup. Below is the full specification breakdown for the system:

Ansaldo Energia AE94.2 Gas Turbines:

Model: Ansaldo Energia AE94.2
Power Output: 185 MW per turbine
Fuel Type: Natural Gas and Diesel (Dual Fuel)
Voltage: 10.5 kV
Frequency: 50 Hz
Hours: Zero hours (Brand new turbines, unused)
Year: 2017
Cooling System: Includes Coolers for effective turbine cooling
Lube System: Includes a Lubrication System for turbine smooth operation
Emission Technology: Equipped with Low Emission (LE) technologies to minimize harmful emissions such as NOx and CO.

Complete Power Plant Package Scope:

This complete power plant includes the following components:

Gas Turbines & Power Generation Equipment:

2 x Ansaldo Energia AE94.2 Gas Turbines (185 MW each)
Alternators: Converts mechanical energy into electrical power generated by the turbines.
Coolers: Used to keep the turbines operating at optimal temperatures.
Lubrication System: Ensures smooth operation of turbines by circulating oil for lubrication.

Heat Recovery & Steam Generation:

HRSG (Heat Recovery Steam Generator): Recovers waste heat from the exhaust gases of the gas turbines to generate steam for additional power generation.
Steam Turbine (100 MW + 18 MW): These steam turbines utilize the generated steam from the HRSG to produce additional power.
Steam Turbine Alternator: Converts mechanical energy from the steam turbine into electrical power.

Steam Systems:

Steam Tank: Regulates and stores steam to ensure consistent supply for power generation.

Auxiliary Systems:

Gas and Water Treatment Systems: Cleans and prepares the fuel and water used in the power generation process to ensure plant efficiency and longevity.

Environmental Management & Safety:

Chimney: For the safe disposal of exhaust gases in compliance with environmental standards.
Fire Fighting System: Provides necessary safety mechanisms to address potential fire hazards in the plant.

Electrical Distribution Systems:

Transformers: For stepping up or stepping down voltage levels for grid compatibility.
High Voltage (HV) and Low Voltage (LV) Cabinets: For efficient power distribution within the power plant.
MCC (Motor Control Center): Controls the operation of various electrical motors in the power plant.
HV Compartment Art: Components for managing high-voltage power distribution and protection.

Control Systems:

Centralized Control System: Monitors and controls all aspects of the power plant, from the turbines to the auxiliary systems.
SCADA System: For real-time remote monitoring and control, ensuring efficient and safe operation.

Key Features of the Ansaldo Energia AE94.2 Power Plant:

Dual-Fuel Operation: The turbines are capable of running on both natural gas and diesel, allowing flexibility based on fuel availability and cost.
Zero Hours: These turbines and the entire power plant setup are brand new, meaning they have not been used previously and have zero operational hours.
High Power Output: Each AE94.2 turbine generates 185 MW of electrical power, making them highly suitable for large-scale power generation.
Steam Cycle: The inclusion of a 100 MW + 18 MW steam turbine and HRSG allows for a combined-cycle configuration, which increases the overall efficiency of the plant.
Low Emission Technology: The turbines are designed to meet stringent environmental standards, incorporating low emission technologies to reduce NOx and other pollutants.
High Efficiency: This combined-cycle setup with gas turbines and steam turbines maximizes the overall efficiency of the power plant.
Complete Turnkey Solution: The plant comes as a complete power generation solution, including turbines, alternators, transformers, steam turbines, fire safety systems, and all necessary infrastructure for operation.

Applications of the Power Plant:

Utility-Scale Power Generation: Ideal for providing base-load or peak-load electricity to the grid.
Combined-Cycle Power Generation: The plant uses the waste heat from the gas turbines to generate additional power through the steam turbine, making it a combined-cycle plant that operates at higher efficiency.
Industrial Applications: Suitable for large industrial operations requiring consistent and reliable power.
Flexible Fuel Operation: With dual-fuel capability, the plant can adapt to fluctuating fuel availability.

Summary of Specifications:

Model: Ansaldo Energia AE94.2 (2 units)
Power Output: 185 MW per turbine
Fuel Type: Dual Fuel (Natural Gas / Diesel)
Voltage: 10.5 kV
Frequency: 50 Hz
Hours: Zero (Brand new)
Year: 2017
Emission Technology: Low Emission (LE)
Total Plant Scope: Gas turbines, alternators, HRSG, steam turbines (100 MW + 18 MW), steam turbine alternator, transformers, fire safety, cooling systems, lube systems, gas & water treatment, control systems
Applications: Utility, Industrial Power Generation, Combined Cycle Power Generation

Conclusion:

This Ansaldo Energia AE94.2 power plant offers high-efficiency, combined-cycle power generation with dual-fuel flexibility. The plant is ideal for large-scale utility or industrial applications, providing a reliable, environmentally friendly, and efficient power solution. The inclusion of both gas turbines and steam turbines in the plant design ensures the highest efficiency through the combined-cycle process. With zero hours of use and new equipment, this power plant is a turnkey solution ready for immediate deployment.

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

General Terms

ReflowX and the seller retain the right to evaluate and approve offers.
Buyers should verify quantities and conditions upon delivery.
After successful engagement, both buyer and seller manage communication for payment terms and delivery schedule.
All parties agree to adhere to ReflowX Terms and Conditions in transactions.
Buyers can request value-added services such as pre-purchase inspections, Expediting & Delivery Services through ReflowX. Contact us!
